The Power List
About the Power List
21 Nov 10
The Power List is basically a collection of current draw figures for lots of guitar effects pedals. You can use it to figure out how much power you need from a power supply, or (which might be just as frequent) to find out why a certain pedal won’t work from the power supply you have……
Boss
21 Nov 10
Compact pedals Pedal Current draw Adapter* AC-2 Acoustic Simulator 18 mA (stated) PSA AW-2 Auto Wah 15 mA (stated) PSA AW-3 Dynamic Wah 45 mA (stated, max) PSA BD-2 Blues Driver 13 mA (stated) PSA BF-2 Flanger 15-18 mA (fluctuating) ACA/PSA BF-2B Bass Flanger 14 mA (stated) ACA 12v BF-3 Flanger 40 mA PSA CE-2…
Danelectro
21 Nov 10
Big box and mini ”food” pedals Pedal Current draw Cool Cat Chorus 32 mA Daddy-O 6 mA DanEcho 44 mA max FabTone 10 mA Fish & Chips EQ 20 mA French Toast Fuzz 8 mA PB&J Delay 35 mA Pepperoni Phaser 4 mA Rocky Road (DJ-20) 24mA Tuna Melt Tremolo 12 mA — FAB series…
Diamond Pedals
21 Nov 10
Pedal Current draw Voltage (max) Bass Comp 18mA 18vDC (24vDC) center positive Boost-EQ 15 mA 9vDC (18vDC) Compressor 15 mA 9vDC (18vDC) Diamond Drive, Diamond Drive SE 15 mA 9vDC (18vDC) Fireburst 12 mA 9vDC (18vDC) Halo Chorus 95 mA 18vDC (24vDC) center positive J-Drive, J-Drive TR, J-Drive Mk3 15 mA 9vDC (18vDC) Marquis…
Digitech
21 Nov 10
Standard pedals Pedal Current draw Bad Monkey 17 mA (stated) Death Metal 21 mA (stated) Grunge 21 mA (stated) Hot Head 17 mA (stated) Screamin’ Blues 23 mA (stated) — X-series Pedal Current draw DigiDelay Dunno, but figure at least 150 mA DigiVerb 125 / 148 mA Hot Rod Rock Distortion ? Hyper Phase 110…
DOD
21 Nov 10
Pedal Current draw FX10 Bi-Fet Preamp 1.2 mA FX25B Envelope Filter 10 mA FX64 Ice Box Chorus 22 mA FX-75B Stereo Flanger 10 mA FX84 Milk Box Compressor 15 mA FX90 8 mA FX96 18 mA DOD 201 Phasor (reissue) 3.1 mA DOD 280 Compressor (reissue) 2.8 mA DOD 690 Chorus 23 mA —
Dunlop/MXR
21 Nov 10
Dunlop Pedal Current draw 105QW Bass wah 4 mA 535Q wah 2 mA GCB-95 CryBaby Wah 0.43 mA GCB-95F Crybaby Classic 2 mA Rotovibe 14mA (stated) — MXR Pedal Current draw 1976 Handwired Dynacomp 1 mA 6 band EQ (black version with switch) 3 mA Blue Box 5 mA CAE Boost/Linedriver 2 mA Carbon Copy…
EBS
21 Nov 10
Pedal Current draw BassIQ 18 mA DPhaser 110 mA DynaVerb 80 mA MetalDrive 18 mA MicroBass II 10mA MultiComp 15mA MultiDrive 15mA OctaBass 10mA Stanley Clarke signature Wah 25mA TremoLo 20mA UniChorus 20mA ValveDrive 12vAC, 500mA WahOne 25mA —
Electro-Harmonix
21 Nov 10
Nano and XO series Pedal Current draw Bass Big Muff Pi 3 mA Bass Blogger 0/8 mA [Power is off in bypass. Positive ground - requires separate power source] Freeze 140 mA Holy Grail Plus 180-195 mA LPB-1 Nano 0.5 / 1.3 mA Deluxe Memory Boy 100 mA Memory Boy 30 mA (45 mA stated)…
Fulltone
21 Nov 10
Pedal Current draw ChoralFlange 15 mA Fulldrive 2 (10th anniversary edition) 35 mA (reported – to me it seems far too high for that circuit) Mini DejaVibe 95-101 mA (fluctuating) OCD 7 mA Plimsoul 12 mA Supa-Trem 8 mA —
